DMX Pixel Neon – DN166004 16X20mm Vertical Bend 60LEDs 10Pixels

Product:DMX Pixel Neon – DN166004 16X20mm
Vertical Bend 60LEDs 10Pixels

Description:

The Colordreamer DMX Flex Neon are flexible strips which can be controlled directly using DMX512.The strip provides flexibility to fit on any curved surface.

All strips are supplied in a 5 meter roll as standard.

We have used superior thickened 3OZ copper tracks to reduce the effects of voltage drop.

CONTACT US

Specification

Models	DN166001	DN166002	DN166003	DN166004
LED
Light Source	SMD 5050	SMD 5050	SMD 5050	SMD 5050
Color	Static White (W:2700K W:3000K W:4000K W:6500K)	Tunable White 2700K to 6500K	RGB	RGBW (W:2700K W:3000K W:4000K W:6500K)
CRI for White LED	Ra>80	Ra>80	–	Ra>80
LED QTY	60LEDs per meter
LED Spacing	16.6mm
Performance
Lumen Output	530lm	830lm	480lm	750lm
Efficacy	44lm/W	46lm/W
Beam Angle	120°
Electrical
Input Voltage	24VDC	24VDC	24VDC	24VDC
Power Consumption	12W per meter	12W per meter	12W per meter	16W per meter
Control
Protocols	DMX512
Addressing	Manual Addressing with Colordreamer Addressing Tool CD-MT512
Pixels	10pixels/m
LEDs per Pixel	6
Pixel Pitch	100mm
Cutting Pitch	100mm
Physical
Material	Copper 3OZ
Housing Color	White
Length	5000mm
Width	16mm
Height	20mm
Mounting	Aluminium Brackets
Environment
Operating Temperature	-20℃ to +60℃
Storage Temperature	-40℃ to +70℃
Humidity	0-90% non-condensing
IP Rating	IP66
Certification	CE
